Mateksys F405 WING V2 Flight Controller Built-in ICM42688P OSD SD Slot |Mechfpv shenzhen

Product name: Mateksys F405 WING V2 Flight Controller with ICM42688P, OSD & Micro‑SD Slot

description:

The Mateksys F405 WING V2 is a dedicated fixed‑wing flight controller powered by STM32F405RGT6 168MHz MCU, equipped with high‑precision ICM42688‑P IMU and DPS310 barometer for stable attitude holding and altitude‑hold performance. Integrated AT7456E OSD chip and micro‑SD blackbox slot support on‑screen display and flight log recording. Built‑in PDB supports 3‑6S LiPo input (9‑30V) with multi‑channel BEC outputs for servos, VTX, camera and peripheral modules. It features 10 PWM outputs, 6 UART ports, 2 I2C buses and built‑in SBUS signal inverter, fully compatible with INAV and ArduPilot firmware. Ideal for RC fixed‑wing planes, flying wings and VTOL drone projects, supplied by Mechfpv Shenzhen.

brand: Mateksys

sku: MTK‑F405‑WING‑V2

offers:

• STM32F405RGT6 168MHz MCU, high‑accuracy ICM42688‑P IMU + DPS310 barometer

• Onboard AT7456E OSD + Micro‑SD slot for blackbox flight logging

• Integrated PDB, 3‑6S LiPo (9‑30V) power input with TVS surge protection

• Multiple BEC outputs: 5V‑2A, 9V/12V‑2A, adjustable Vx servo BEC up to 5A continuous

• 10‑channel PWM outputs, 6×UART, 2×I2C, built‑in SBUS inverter

• Native support for INAV & ArduPilot firmware, perfect for flying‑wing / VTOL / fixed‑wing builds

• Sourced & supplied by Mechfpv Shenzhen

availability: In Stock, Fast Shipping
